Solid cone nozzle design characteristics
G - W/H - WSQ series nozzle can produce solid spray cone shape, is the feature of the injection area into a round shape (square), the jet Angle is 120 ° to 125 °, 93 °, 115 °).
This kind of nozzle jet spray evenly in the whole flow area, droplet size medium to large.In need a thorough covering an area of jet application fields can produce a great result.
The uniform spray distribution is derived from the unique blade design and precise internal size, ensure the accurate and stable performance.
G W, GG W wide-angle solid cone nozzle with three body structure (nozzle body/cap/blades), the blade can be removed.This nozzle is especially suitable for installation on the manifold and branch pipe, in order to remove and check the cap and blade and don't have to be removed from the manifold nozzle body.
H - WSQ, HH - WSQ wide-angle square solid cone nozzle is suitable for installation in uniform coverage of the rectangular area need.
1-1/4 "and larger size of the nozzle is casting type, has a removable blade.
The general application
When washing and bleaching process
, low coke quenching and cooling of metals and other materials.
Low in the treatment of large ore, coal, limestone, sand and gravel inhibition in the process of powder dust easily.
Low exhaust gas cleaning and cooling to dust removal and other products of combustion.
Low flooded immersion flammable items and locker so as to achieve the purpose of fire prevention
The low foam disintegration and deaeration
Low water in the process of chemical reaction
